Phenolic Case Gauges

SKU:P-05

Category:

Pressure

Description
Datasheet

Product Description

SPECIAL FEATURES

Phenolic Case With Solid Front Design

Blow out back

Standard followed ASME-B.40.1

Helium Leak Tested

Built in Stabilizer Movement

Ready For Oxygen Use

Internal Vacuum /Over Pressure Stops

IP 66

SPECIFICATION

Ambient Temperature: -4?(-20?) to+150?(+65?)

Process Temperature: Max.392?(200?)

Operating Pressure Range: 75% of scale value

Over Pressure Limit: 150% of Max.scale value

Case & Bezel: Phenolic

Joints: Tig Argon Arc Welding

Protection: IP 66

Socket: AISI 316L

Bourdon: AISI 316L

Movement: AISI 304

Dial: Aluminum

Pointer: Micro Zero Adjustable

Window: Safety Glass

Gasket: Viton

Ranges: Vacuum to 40,000psi

ACCURACY AS PER ASME B.40.1

4.5″ : 0.5-0.5-0.5 (Grade 2A)
